Ⅰ. Main Technical Parameters：

1. Working process：

Reserving holder → up-roll → taking → Rectify → Leveling → Sizing→

Shearing→ delivery→ piler

2. The material parameters of inlet

Material of Steel Coil:        hot-rolled steel coil Q235/SS41/SPHC/SS400

Thickness of Steel Coil:      3mm～ 16mm

Width of Steel Coil:          600mm～1650mm

Inner diameter of Steel Coil:  Φ 508mm, Φ 610mm, Φ 762mm

Outer diameter of Steel Coil:  Φ 1000mm～ Φ2000mm

Weight of Steel Coil:          MAX 35000Kg

3. The material parameters of outlet

Leveling accuracy:

The length direction:        ±0.5mm (for length of 2m)

The diagonal direction:      ±1.0mm (for length of 2m)

Leveling accuracy:          ≤2.0mm/m2

The length of stacker:       1000mm～9000mm

The load-bearing of stacker:  MAX 20000Kg

4. General Data on Machine Unit

Design speed:               MAX 35m/min

Machine unit direction:        left to right or right to left

Equipment color:  According to the customer provide the swatches

Total power:                 ≈300KW

Power Source:              AC380V±10% 50Hz

Floor Area (length × width):   ≈30m×10m

Operating Environment: ambient temperature: -10℃ ～45℃

Relative Humidity:           ≤80%

Level of Protection:          IP30
