1. Materials to form: According to the customers’ requirement Used for 200mm-600mm (one-sided slide-able, adjustable by electric)

2. Forming steps: About 18 steps

3. Material of rollers:GCr15 steel, precision-machined, high frequency quenching HRC58-62, diameter of rollers: ＞￠150

4. Material of main shaft : 45# high quality steel (diameter＞￠50)

5. Chains’ material: 45# steel, high frequency quenching, circular pitch: 38.1; number of teeth: 13

6. Cutting: Hydraulic cutting; quenching HRC58-62

7. Electronic control: PLC control

8. Dimension of machine: 12000mmX2000mmX900mm

10. Drive system: Chain drive, 7.5KW main motor power, working speed: 3-15m/min;

11. Welding structure: material of fixed beam and walking beam: hot-rolled steel, the base and rack are be gantry planer processing after welded, work platform is not allowed stress deformation; main machine table-board’s plainness ＜2mm/1000mm

12. Parts: Slide: imported from Japan; bearing: Zhonghang Brand of Harbin

13. Punching: Punching the holes at the press machine before forming the shapes

14. Bending: Bending after the hydraulic cutting
