1.Material thickness(mm)：1.2-2mm, Max feeding width：900mm. Strength yield≤G350MPa

2.Roller QTY：CU shape steel roller 18 groups.

3.Install type：memorial archway

4.Roller form：Coaxial design

5.Roller material: GCr15(ball bearing steels)quenching treatment. Surface is hard chrome plating, HRC56°-62° Depth of quenching ：8mm

6.Main shaft material: High quality 40crthermal refining with surface hard chrome plating.

7.Drive mode：Cycloidal pin gear speed reducer, Motor power：18.5KW

8.Working speed：8-12M/min

9.Hydraulic station motor power：5.5KW

10.shear mode：cutting after forming

11.Die and blade material：Cr12mov

12.Electronic system：Industrial computer Panasonic PLC、YASKAWA frequency converter、Omron encoder、Schneider brand

13.Dimension of the machine：18m×1.1m×1.5m
